Technical Specifications
Frameset
Frame
Specialized Diverge FACT 9r carbon, SWAT™ Door integration, Future Shock suspension, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc, UDH dropout
Suspension
Fork
Future Shock 3.3 w/ Smooth Boot, FACT Carbon 12x100mm, thru-axle, flat-mount disc
Brakes
Front Brake
SRAM Force E1, hydraulic disc
Rear Brake
SRAM Force E1, hydraulic disc
Drivetrain
Bottom Bracket
SRAM DUB BSA 68 Wide
Rear Derailleur
SRAM Force AXS E1 XPLR, 13-speed
Shift Levers
SRAM Force AXS E1, hydraulic disc
Chain
SRAM Force E1
Cassette
SRAM Force E1 XPLR, 13-speed, 10-46t
Crankset
SRAM Force E1 XPLR, DUB Wide, 40t, Quarq Power Meter
Wheels & Tires
Inner Tubes
700x32-50mm, 40mm Presta valve
Front Tire
Tracer TLR All Terrain Gravel Tire 700x45, Tan Sidewall, Tubeless Ready
Rear Tire
Tracer TLR All Terrain Gravel Tire 700x45, Tan Sidewall, Tubeless Ready
Front Wheel
Roval Terra CL III, 27mm internal width, tubeless ready, 25.5mm depth, 21h, DT 350 hub, Centerlock disc, DT Swiss Revolution spokes
Rear Wheel
Roval Terra CL III, 27mm internal width, tubeless ready, 25.5mm depth, 24h, DT 350 hub, Centerlock disc, DT Swiss Revolution spokes
Cockpit
Saddle
Power Pro Mirror, hollow Ti rails
SeatPost
Roval Terra Carbon Seat Post, 20mm Offset
Handlebars
Roval Terra, carbon, 103mm drop x 70mm reach x 12º flare
Seat Binder
Specialized Alloy, 30.8mm
Stem
Specialized Pro SL, alloy, 4-bolt
Tape
Supacaz Super Sticky Kush
Accessories
SWAT
SWAT 4.0 internal downtube storage
Product Details
Product ID
296445
Weight
Weight Size
56
Weight
8.72 kg (19 lb, 3.6 oz)
Geometry
| 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Crank Length | 165 | 170 | 172.5 | 172.5 | 175 | 175 |
| Handlebar Width | 380 | 400 | 420 | 420 | 440 | 440 |
| Stem Length | 60 | 70 | 80 | 90 | 100 | 100 |
| Saddle Width | 155 | 155 | 143 | 143 | 143 | 143 |
| Seatpost Length | 330 | 330 | 380 | 380 | 380 | 380 |
| Stack | 563 | 578 | 592 | 610 | 634 | 659 |
| Reach | 365 | 374 | 387 | 400 | 412 | 425 |
| Head Tube Length | 90 | 104 | 116 | 135 | 161 | 187 |
| Head Tube Angle | 70 | 70.5 | 71 | 71 | 71 | 71 |
| BB Drop | 85 | 85 | 85 | 85 | 85 | 85 |
| Trail | 72 | 68 | 65 | 65 | 65 | 65 |
| Fork Length, Full | 391 | 391 | 391 | 391 | 391 | 391 |
| Fork Rake/Offset | 55 | 55 | 55 | 55 | 55 | 55 |
| Front Center | 604 | 613 | 626 | 645 | 665 | 686 |
| Chainstay Length | 430 | 430 | 430 | 430 | 430 | 430 |
| Wheelbase | 1019 | 1031 | 1041 | 1060 | 1081 | 1102 |
| Top Tube Length, Horizontal | 521 | 537 | 556 | 575 | 593 | 613 |
| Bike Standover Height | 700 | 725 | 754 | 779 | 805 | 832 |
| Seat Tube Length | 400 | 430 | 470 | 500 | 530 | 560 |
| Seat Tube Angle | 74.5 | 74 | 74 | 74 | 74 | 74 |
