Diverge STR Expert

Diverge STR Expert

96223-3052

R 125,000.00
R 125,000.00
Sale Sold out
Taxes included.
Size
Color

CLICK HERE TO VIEW PICK UP IN STORE AVAILABILITY

Bell's Cycling

Shop1 A Riverside Junction, R40,Riverside, Nelspruit, 1200

Trading Hours: Mon - Fri: 08:00am to 17:00pm | Sat: 09:00am to 14:00pm | Sun: Closed

Diverge STR Expert

With Future Shock suspension front and rear, the new Diverge STR delivers compliance without compromise. By suspending the rider—instead of the bike—Future Shock technology increases control and efficiency while decreasing fatigue, so you’ll be riding farther and faster over chunkier terrain than you believed possible. And the Diverge STR does this without the weight, sluggish pedal response, and inefficiency of other suspension systems. The Diverge STR Expert starts with our FACT 11r carbon frameset with front and rear Future Shock suspension. It’s built with SRAM’s Rival eTap AXS Eagle groupset for fast, efficient shifting with a 10-50 cassette to ensure you have the gearing to tackle any ride. The bike rolls on the Roval Terra C wheels with 42mm Tracer Pro tires. Adventure Gear alloy handlebars, an S-Works carbon seatpost, and Power Expert saddle complete the package making the Diverge STR the most capable Diverge ever.

  • By suspending the rider with damped, tunable travel—20mm front/30mm rear—Future Shock Technology absorbs bump forces to boost your control and capability while retaining the efficiency and responsiveness of a rigid frame. Because as far as power transfer goes, it is a rigid frame. Power to the pedals makes the bike jump like a scared cat. You’re efficient, you’re comfortable, you’re in control. Your bike is light, nimble, and responsive.
  • The new Diverge doesn’t just have gorgeous lines, it has perfect curves too. Future Shock Rear puts 30mm of rear travel in the ideal path to smooth out rough road. Its hydraulic damping controls travel to eliminate “bobbing” under power and ensure big hits never catapult you from the saddle, all without compromising fit or pedaling efficiency.
  • Born from decades of innovation and our Smoother is Faster philosophy, Future Shock was created to develop bikes that win on cobblestones, but it’s found its purest expression on gravel. It’s 20mm of adjustable, damped front travel that keeps you in control and on target, all while protecting your hands, arms, and shoulders from the battering.
    View full details

    Technical Specifications

    COCKPIT

    Saddle

    Body Geometry Power Expert, titanium rails

    Stem

    Future Stem, Comp

    SeatPost

    S-Works Carbon Seat Post, 20mm Offset

    Seat Binder

    Specialized Alloy, 33.3mm

    Handlebars

    Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare

    Tape

    Supacaz Super Sticky Kush



    SUSPENSION

    Fork

    Future Shock 2.0 w/ Damper, Smooth Boot, FACT carbon, 12x100 mm thru-axle, flat-mount

    FRAMESET

    Frame

    Diverge FACT 11r carbon frameset with front and rear Future Shock suspension, SWAT™ Door integration, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc



    ACCESSORIES

    SWAT

    Integrated SWAT door, internal storage system



    WHEELS & TIRES

    Inner Tubes

    Presta valve, 48mm

    Rear Tire

    Tracer Pro 2BR, 700x42

    Front Tire

    Tracer Pro 2BR, 700x42

    Front Wheel

    Roval Terra C, 25mm inner width carbon rim, 32mm depth, NEW DT 370 hub, 24h, DT Swiss Comp Race spokes

    Rear Wheel

    Roval Terra C, 25mm inner width carbon rim, 32mm depth, NEW DT 370 Star Ratchet hub, 24h, DT Swiss Comp Race spokes



    DRIVETRAIN

    Bottom Bracket

    SRAM DUB BSA 68

    Rear Derailleur

    SRAM GX Eagle AXS, w/ battery cover

    Chain

    SRAM GX Eagle, 12-speed

    Cassette

    SRAM NX Eagle PG-1230, 12-speed, 11-50t

    Crankset

    SRAM Rival 1 Wide

    Shift Levers

    SRAM Rival eTap AXS

    Chainrings

    40t



    BRAKES

    Front Brake

    SRAM Rival eTAP AXS, hydraulic disc

    Rear Brake

    SRAM Rival eTAP AXS, hydraulic disc

    * Specifications are subject to change without notice

    Geometry

     495254565861
    Crank Length165mm170mm172.5mm172.5mm175mm175mm
    Handlebar Width380mm400mm420mm420mm440mm440mm
    Stem Length60mm70mm80mm90mm100mm100mm
    Saddle Width155mm155mm143mm143mm143mm143mm
    Seatpost Length350mm350mm350mm350mm350mm350mm
    Stack569mm576mm593mm609mm633mm659mm
    Reach365mm374mm383mm392mm401mm410mm
    Head Tube Length100mm100mm115mm130mm155mm182mm
    Head Tube Angle70°70.5°71.25°71.75°71.75°71.75°
    BB Height270mm265mm265mm265mm265mm265mm
    BB Drop80mm85mm85mm85mm85mm85mm
    Trail69mm66mm61mm57mm57mm57mm
    Fork Length, Full390mm390mm390mm390mm390mm390mm
    Fork Rake/Offset55mm55mm55mm55mm55mm55mm
    Front Center607mm612mm619mm629mm645mm663mm
    Chainstay Length429mm429mm429mm429mm429mm429mm
    Wheelbase1023mm1027mm1034mm1044mm1060mm1078mm
    Top Tube Length, Horizontal527mm540mm556mm570mm586mm602mm
    Bike Standover Height704mm730mm753mm778mm804mm833mm
    Seat Tube Length390mm430mm470mm500mm530mm560mm
    Seat Tube Angle74.5°74.25°74°74°74°74°
