Technical Specifications
Frameset
Frame
FACT 11m Carbon, Progressive XC Race Geometry, Rider-First Engineered™, SWAT downtube storage, threaded BB, 12x148mm UDH compatible rear dropout, internal cable routing, 120mm of travel
SWAT
SWAT internal downtube storage
Seat Binder
Specialized Alloy 34.9, Steel Bolt
Suspension
Fork
RockShox SID Select+, Ride Dynamics developed 3 position, TwistLoc remote adjust, Debon Air, 15x110mm, 44mm offset, 120mm Travel
Rear Shock
RockShox SIDLuxe Select+, Ride Dynamics developed 3 position, TwistLoc remote adjust, Solo Air, 190x45mm
Brakes
Front Brake
Shimano XT 8200, 2-piston caliper, hydraulic disc, 180mm rotor
Rear Brake
Shimano XT 8200, 2-piston caliper, hydraulic disc, 180mm rotor
Drivetrain
Chainrings
32T
Chain
Shimano XT
Crankset
Shimano XT 8200, 34t, XS:165mm, S-M:170mm, L-XL:175mm
Shift Levers
Shimano XT Di2
Rear Derailleur
Shimano XT Di2, 12-speed
Cassette
Shimano XT M8200, 12-speed, 10-51
Bottom Bracket
Shimano, BB-MT801, Threaded
Wheels & Tires
Front Wheel
Roval Control SL V, Hookless carbon, 29mm inner width, tubeless ready, DT Swiss 370 hub, Sapim D-Light Straight Pull, 6 bolt
Rear Wheel
Roval Control SL V, Hookless carbon, 29mm inner width, tubeless ready, DT Swiss 370 hub, Sapim D-Light Straight Pull, 6 bolt
Rear Tire
Specialized Fast Trak, Flex Lite Casing, T5/T7 Compound, TLR, 29x2.35
Front Tire
Specialized Fast Trak, Flex Lite Casing, T5/T7 Compound, TLR, 29x2.35
Inner Tubes
Specialized Turbo Tube
Cockpit
Saddle
Body Geometry Power Comp, steel rails
Grips
SRAM Slip on with Twist-Loc
Handlebars
Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp
Stem
Specialized XC, 3D-forged alloy, 4-bolt, 6-degree rise
SeatPost
X-Fusion Manic, 30.9, XS: 100mm, SM: 125mm, M: 150mm, L-XL: 170mm Travel, 0mm offset
Product Details
Product ID
291798
Weight
Weight
11.17 kg (24 lb, 10.0 oz)
Weight Size
MD
Geometry
| S | M | L | XL | |
|---|---|---|---|---|
| Crank Length | 170mm | 170mm | 175mm | 175mm |
| Handlebar Width | 760mm | 760mm | 760mm | 760mm |
| Stem Length | 60mm | 60mm | 60mm | 60mm |
| Saddle Width | 155mm | 143mm | 143mm | 143mm |
| Seatpost Length | 125mm | 125mm | 150mm | 170mm |
| Front Center | 716mm | 747mm | 778mm | 811mm |
| Seat Tube Length | 390mm | 410mm | 450mm | 500mm |
| Stack | 597mm | 598mm | 610mm | 628mm |
| Head Tube Angle (high) | 66.4° | 66.4° | 66.4° | 66.4° |
| Trail | 117mm | 117mm | 117mm | 117mm |
| Chainstay Length | 435mm | 435mm | 435mm | 435mm |
| Reach (low) | 420mm | 450mm | 475mm | 500mm |
| Seat Tube Angle | 76° | 75.5° | 75.5° | 75.5° |
| BB Height (low) | 324mm | 326mm | 328mm | 328mm |
| Fork Length, Full | 530mm | 530mm | 530mm | 530mm |
| Head Tube Length | 92mm | 95mm | 110mm | 130mm |
| Top Tube Length, Horizontal | 569mm | 605mm | 633mm | 662mm |
| Wheelbase | 1147mm | 1179mm | 1210mm | 1243mm |
| BB Height (high) | 329mm | 331mm | 333mm | 333mm |
| Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm |
| Bike Standover Height | 755mm | 760mm | 769mm | 774mm |
| BB Drop (low) | 46mm | 44mm | 42mm | 42mm |
| Head Tube Angle (low) | 65.9° | 65.9° | 65.9° | 65.9° |
