Technical Specifications
Frameset
Frame
S-Works FACT 12m Carbon with Carbon Shock Extension, Progressive XC Race Geometry, Rider-First Engineered™, SWAT downtube storage, threaded BB, 12x148mm UDH compatible rear dropout, internal cable routing, 120mm of travel, Optimized for wireless drivetrain and seatpost
Seat Binder
Specialized Alloy 34.9, Titanium Bolt
Suspension
Fork
FOX 34 SL Factory, GRIP X Damper, HSC, LSC, LSR adjust, 130mm travel, 44mm offset, 15x110mm
Rear Shock
FOX FLOAT Factory, EVOL LV, Ride Dynamics Tuned, 2-position compression adjust, 190x45mm
Brakes
Front Brake
Shimano XTR 9220, 4-piston caliper, hydraulic disc, 180mm rotor
Rear Brake
Shimano XTR 9220, 4-piston caliper, hydraulic disc, 180mm rotor
Drivetrain
Chainrings
32T
Chain
Shimano XTR
Crankset
Shimano XTR 9200, 4iiii power meter, 170mm
Shift Levers
Shimano XTR Di2
Rear Derailleur
Shimano XTR Di2, 12-speed
Cassette
Shimano XTR, 12 Speed, 10-51T
Bottom Bracket
Shimano, BB-MT801, Threaded
Wheels & Tires
Front Wheel
Roval Control SL VI, Hookless carbon, 29mm inner width, tubeless ready, 24H, Industry 9 Solix hub, Roval Carbon spokes w/ Ti end pieces, centerlock
Rear Wheel
Roval Control SL VI, Hookless carbon, 29mm inner width, tubeless ready, 24H, Industry 9 Solix hub, Roval Carbon spokes w/ Ti end pieces, centerlock
Rear Tire
Specialized Ground Control, Grid Lite Casing, T5/T7 Compound, TLR, 29x2.35
Front Tire
Specialized Purgatory, GRID Casing, T9 Compound, TLR, 29x2.4
Inner Tubes
Specialized Turbo Tube
Cockpit
SeatPost
FOX Factory Transfer Neo, 30.9mm, S: 125mm, M:150mm, L/XL: 175mm
Grips
Specialized Trail Grips
Stem
Industry Nine A35, 50mm, 35mm clamp
Handlebars
Roval Control Rise Carbon Handlebar, 780mm wide, 20mm rise, 35mm clamp
Saddle
Specialized S-Works Power, Carbon Rails
Accessories
SWAT
SWAT internal downtube storage
Product Details
Product ID
291453
Weight
Weight
11.17 kg (24 lb, 10.0 oz)
Weight Size
MD
Geometry
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Crank Length | 165mm | 170mm | 170mm | 175mm | 175mm |
| Handlebar Width | 760mm | 760mm | 760mm | 760mm | 760mm |
| Stem Length | 50mm | 50mm | 50mm | 50mm | 50mm |
| Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm |
| Seatpost Length | 125mm | 125mm | 150mm | 170mm | 170mm |
| Stack | 606mm | 600mm | 601mm | 613mm | 632mm |
| Reach | 385mm | 415mm | 445mm | 470mm | 495mm |
| Head Tube Length | 92mm | 92mm | 95mm | 110mm | 130mm |
| Head Tube Angle (low) | 65.4° | 65.4° | 65.4° | 65.4° | 65.4° |
| Head Tube Angle (high) | 65.9° | 65.9° | 65.9° | 65.9° | 65.9° |
| BB Height (low) | 322mm | 327mm | 329mm | 331mm | 331mm |
| BB Height (high) | 327mm | 333mm | 335mm | 337mm | 337mm |
| BB Drop (low) | 49mm | 43mm | 41mm | 39mm | 39mm |
| Trail | 120mm | 120mm | 120mm | 120mm | 120mm |
| Fork Length, Full | 540mm | 540mm | 540mm | 540mm | 540mm |
| Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm | 44mm |
| Front Center | 690mm | 720mm | 751mm | 782mm | 815mm |
| Chainstay Length | 435mm | 435mm | 435mm | 435mm | 435mm |
| Wheelbase | 1121mm | 1151mm | 1183mm | 1214mm | 1247mm |
| Bike Standover Height | 754mm | 761mm | 766mm | 775mm | 779mm |
| Seat Tube Length | 370mm | 390mm | 410mm | 450mm | 500mm |
| Seat Tube Angle | 76° | 75.5° | 75° | 75° | 75° |
| Top Tube Length, Horizontal | 535mm | 569mm | 605mm | 633mm | 662mm |
Size Chart
