S-Works Epic LTD
Hey you, yeah, you...the one with the scale out seeing which of the six identical tires on the shelf is the lightest. Sure, some might call you a bit obsessive, but no worries, here, the S-Works Epic LTD is speaking exactly the same language. Countless design hours, endless test laps, terabytes of telemetry data—all of it to make sure not a single ounce of speed was left on the table.
Mixing hardtail efficiency and full-suspension capability to impressively quick results, the S-Works Epic LTD has always been defined by obsessive commitment to speed. Well, that and over 100 World Cup wins and podiums too.
A SMARTER BRAIN
True to form, the latest Epic continues the tradition, taking advantage of the most efficient BRAIN suspension we’ve ever created to ensure it’s always on a first-name-basis with fast.
Re-engineered hand-in-hand with the new Epic, the latest BRAIN design resets the expectation for efficiency, employing a new race-tuned pedaling platform to ensure every watt possible is translated into forward motion, while handily soaking up momentum-killing chatter and big hits alike—all more smoothly than ever.
FRAME-CHANGER
Redesigned with a focus on efficient power transfer and better handling performance, the S-Works Epic LTD frame features a 15-percent stiffer rear triangle in order to take full advantage of the BRAIN’s new race-tuned pedaling platform. A dedicated layup schedule and the use of our top-shelf FACT 12m Carbon takes weight savings yet a step further than it’s stablemates, while the pièce de résistance comes in the form of a carbon fiber shock link, combining to shave a total of over 100 grams from the previous generation S-works frame—no easy task, mind you.
Pairing perfectly with the Brain rear shock for the most balanced suspension perfomance on an Epic yet, the S-Works' Position-Sensitive Brain fork benefits from RockShox’s svelte-yet-stiff SID SL Ultimate chassis, improving front-end stiffness and handling precision while keeping the grams at bay.
- If speed could talk, it’d introduce itself as the all-new S-Works Epic frame. Offering 100-millimeters of brilliantly efficient Brain-controlled travel, the S-Work Epic increases rear-triangle stiffness for peerless power transfer, while the use of FACT 12m carbon, a dedicated layup and a full carbon shock link also make it the lightest full suspension frame we’ve ever created, all while offering the most capable handling in an Epic yet. Nice to meet you, speed.
- Pairing 110 millimeters of the most efficent travel on earth with RockShox's svelte-yet-stiff SID SL Ultimate chassis, the RockShox SID SL Ultimate BRAIN fork serves as the pinnacle of XC-race supsension perfection.
Share
Technical Specifications
COCKPIT
Saddle
Body Geometry Power Comp 143
SeatPost
Roval Control SL carbon seatpost, Two-bolt clamp, 0mm offset, 415 x 30.9
Handlebars
Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp
Stem
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise 90mm
Tape
Specialized Trail Grips
WHEELS
Spokes
Sapim D-Light Straightpull, Front: Two-cross (1:1) 28 count, R: 304mm, L: 304mm - Rear: Two-cross (1:1) 28 count, DS: 304mm NDS: 304mm
Rims
Control Alloy Asymmetric, 6013 Alloy Shot-Pened, 29", Disc Brake, Zero Bead Hook Design, Tubeless Compatible, Compatible with Tire Inserts
Rear Hub
DT Swiss 350 Straight-pull 6-bolt, Star Ratchet 36t internals (10 degs) , 110x15mm & 148x12mm, Sram XD Freehub (Convertible freehub )
Front Hub
DT Swiss 350
Rear Tire
Specialized Renegade, Control Casing, T5 Compound, 29x2.35
Front Tire
Specialized S-Works Fast Trak,Control Casing, T5 Compound, 29x2.35
Inner Tubes
Specialized Turbo Tube
SUSPENSION
Fork
RockShox SID SL ULTIMATE BRAIN, Top-Adjust Brain damper, Debon Air, 15x110mm, 44mm offset, 110mm Travel
Rear Shock
RockShox-Specialized BRAIN, Rx XC Tune, 5 Position Platform Adjust, Rebound Adjust, Integraded Extension, 265x52.5mm
FRAMESET
Frame
S-Works FACT 12m Carbon, Progressive XC Race Geometry, Rider-First Engineered™, threaded BB, 12x148mm UDH compatible rear spacing, internal cable routing, 100mm of travel
Seat Binder
Specialized Alloy 34.9, Titanium Bolt
DRIVETRAIN
Shift Levers
SRAM AXS POD Controller
Cassette
SRAM XS 1275, 12-speed, 10-52t
Bottom Bracket
SRAM DUB Threaded Wide
Crankset
SRAM GX Eagle, DUB, 170mm
Chain
SRAM GX Eagle T-Type chain
Rear Derailleur
SRAM GX Eagle AXS Transmission
Chainrings
32t
BRAKES
Front Brake
SRAM Level Bronze Stealth, 4-piston caliper, hydraulic disc, 160mm rotor
Rear Brake
SRAM Level Bronze Stealth, 4-piston caliper, hydraulic disc, 160mm rotor
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
S | M | L | XL | |
---|---|---|---|---|
Crank Length | 170mm | 170mm | 175mm | 175mm |
Handlebar Width | 760mm | 760mm | 760mm | 760mm |
Stem Length | 60mm | 70mm | 70mm | 70mm |
Saddle Width | 155mm | 143mm | 143mm | 143mm |
Seatpost Length | 100mm | 125mm | 150mm | 150mm |
Stack | 586mm | 591mm | 605mm | 623mm |
Reach | 415mm | 445mm | 470mm | 495mm |
Head Tube Length | 95mm | 100mm | 115mm | 135mm |
Head Tube Angle | 67.5° | 67.5° | 67.5° | 67.5° |
BB Height | 324mm | 324mm | 324mm | 324mm |
BB Drop | 48mm | 48mm | 48mm | 48mm |
Trail | 106mm | 106mm | 106mm | 106mm |
Fork Length, Full | 505mm | 505mm | 505mm | 505mm |
Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm |
Front Center | 687mm | 719mm | 750mm | 782mm |
Chainstay Length | 433mm | 433mm | 433mm | 433mm |
Wheelbase | 1116mm | 1148mm | 1179mm | 1211mm |
Bike Standover Height | 763mm | 766mm | 776mm | 788mm |
Seat Tube Length | 400mm | 430mm | 470mm | 520mm |
Seat Tube Angle | 75.8° | 75.5° | 75.5° | 75.5° |
Top Tube Length, Horizontal | 563mm | 598mm | 626mm | 656mm |
